| Video Input & Output |
| Total Video Inputs |
10 |
| Total Video Outputs |
6 |
| SDI Rates |
1.5G, 3G, 6G, 12G |
| SDI Audio Inputs |
8 channel embedded audio pada seluruh SDI input |
| SDI Audio Outputs |
16 channel embedded audio pada seluruh SDI output |
| SDI AUX Outputs |
Any of the 6 SDI outputs |
| SDI Preview Outputs |
Any of the 6 SDI outputs |
| SDI Program Outputs |
Any of the 6 SDI outputs |
| Down Converted SDI Program Output |
1 |
| Webcam Output |
1 × USB-C, mendukung 720p atau 1080p pada program frame rate |
| Multiview Output |
1 × 12G-SDI |
| Video Standards |
| HD Video Standards |
720p50/59.94/60, 1080i50/59.94/60, 1080p23.98/24/25/29.97/30/50/59.94/60 |
| Ultra HD Video Standards |
2160p23.98/24/25/29.97/30/50/59.94/60 |
| Video Sampling |
4:2:2 |
| Color Precision |
10-bit |
| Color Space |
Rec. 709, Rec. 2020 |
| SDI Auto Switching |
Otomatis mendeteksi 1.5G-SDI, Level A/B 3G-SDI, 6G-SDI dan 12G-SDI |
| Video Input Re-Sync |
Seluruh 10 input |
| Frame Rate & Format Converter |
Seluruh 10 input |
| Processing & Keying |
| Upstream Keyers |
4 |
| Downstream Keyers |
1 |
| Advanced Chroma Keyers |
4 |
| DVE |
1 |
| Linear/Luma Keyers |
5 |
| Transition Keyer |
1 Stinger, 1 DVE |
| Total Layers |
7 |
| Pattern Generators |
5 |
| Color Generators |
2 |
| Routable Windows |
16 |
| Talkback Support |
Yes |
| Mix Minus Support |
Yes |
| Multi View & Media Player |
| Multi View Monitoring |
1 × multiview, configurable menjadi 16, 13, 10, 7 atau 4 views |
| Multi View Standard |
HD atau Ultra HD |
| Media Players |
2 |
| Media Player Channels |
Fill dan key untuk setiap media player |
| Still Image Capacity |
20 |
| Clip Capacity |
2 × hingga 2160p60 |
| Clip Length 720 HD |
1600 frames |
| Clip Length 1080 HD |
800 frames |
| Clip Length 2160 UHD |
200 frames |
| Still Image Format |
PNG, TGA, BMP, GIF, JPEG, TIFF |
| Video File Format |
TGA Sequence |
| Audio File Format |
WAV, MP3, AIFF |
| Audio |
| Audio Inputs |
2 × balanced 1/4" Jack, 1 × 5-pin XLR Talkback |
| Audio Outputs |
1 × 5-pin XLR Talkback |
| Audio Mixer |
28-channel mixer |
| Audio Control |
On/Off/Audio-Follow-Video, level & peak metering, master gain |
| Audio Processing |
6-band parametric EQ, Expander, Gate, Compressor dan Limiter |
| USB Audio Output |
Digital audio output melalui USB-C dan integrasi dengan Fairlight Live |
| Connectivity & Control |
| Control Panel Connection |
Ethernet; direct connection antara panel dan chassis atau melalui network |
| Control Panel |
Front fascia emergency switching, ATEM Software Control atau optional hardware panel |
| Software Control |
ATEM Software Control |
| Ethernet |
10/100/1000 BASE-T |
| Computer Interface |
1 × USB-C, mendukung USB 2.0 |
| Reference Input |
Tri-Sync atau Black Burst |
| Internal Timecode Generator |
Yes |
| Talkback |
RJ45 untuk third-party talkback systems |
| Tally Output |
Menggunakan Blackmagic Design GPI and Tally Interface melalui Ethernet (produk terpisah) |
| Down Conversion |
1 × selectable HD down converted output |
| Software & Operating System |
| Software Updates |
Melalui USB atau Ethernet menggunakan komputer Mac atau Windows, termasuk ATEM Setup Utility |
| Mac OS |
macOS 14.0 Sonoma, macOS 15.0 Sequoia atau lebih baru |
| Windows |
Windows 10 dan Windows 11 |
| Display & Fisik |
| Front Panel |
Built-in 2.2" LCD monitor, 10 LED buttons, 4 source buttons, 6 talkback selection/mix buttons, menu control knob, set button dan front panel lock |
| Processing Delay |
< 10 lines |
| Power Supply |
1 × internal 100–240V AC |
| Power Usage |
90W |
| Physical Installation |
2/3 rack unit width, 1 rack unit height |
| Optional Rack Accessory |
Blackmagic Universal Rack Shelf |
| Operating Temperature |
0°C hingga 40°C |
| Storage Temperature |
-20°C hingga 60°C |
| Relative Humidity |
0% hingga 90% non-condensing |
