| Video Input & Output |
| SDI Video Inputs |
8 |
| SDI Video Outputs |
12 |
| SDI Rates |
1.5G, 3G, 6G, 12G |
| HDMI Video Outputs |
1 × HDMI 2.0 |
| SDI AUX Outputs |
10 × 12G-SDI |
| SDI Program Output |
1 |
| SDI Audio Inputs |
4 channel embedded audio pada seluruh SDI input |
| SDI Audio Outputs |
16 assignable channels |
| Video Input Re-Sync |
Pada seluruh 8 input |
| Frame Rate & Format Converter |
Pada seluruh 8 input |
| Video Standards |
| HD Input Standards |
720p50/59.94/60; 1080i50/59.94/60; 1080p23.98/24/25/29.97/30/50/59.94/60 |
| Ultra HD Input Standards |
2160p23.98/24/25/29.97/30/50/59.94/60 |
| Video Sampling |
4:2:2 |
| Color Precision |
10-bit |
| Color Space |
Rec. 709, Rec. 2020 |
| SDI Auto Switching |
1.5G-SDI, Level A/B 3G-SDI, 6G-SDI dan 12G-SDI |
| Audio |
| Audio Inputs |
2 × XLR balanced analog, 1 × BNC 32 Ch MADI digital, 2 × RCA stereo analog, 1 × 5-pin XLR Talkback |
| Audio Outputs |
4 × 1/4" Jack analog, 1 × BNC 64 Ch MADI digital hingga 50 active, 1 × 5-pin XLR Talkback |
| Audio Mixer |
58-channel mixer |
| Audio Processing |
6-band parametric EQ, Expander, Gate, Compressor dan Limiter |
| Processing & Keying |
| Mix Effects Rows |
1 |
| Upstream Keyers |
4 |
| Downstream Keyers |
2 |
| Advanced Chroma Keyers |
4 |
| SuperSource |
1 |
| DVE |
2 |
| Linear/Luma Keyers |
7 |
| Transition Keyer |
1 Stinger, 1 DVE |
| Total Layers |
8 |
| Pattern Generators |
7 |
| Color Generators |
2 |
| Multiview & Media Player |
| Multiview Outputs |
1 × 12G-SDI dan 1 × HDMI 2.0 |
| Multiview Layout |
4, 7, 10, 13 atau 16 views |
| Media Players |
2 |
| Still Image Capacity |
20 |
| Media Pool Clip Capacity |
2 × hingga 2160p60 |
| Clip Length 720 HD |
720 frames |
| Clip Length 1080 HD |
360 frames |
| Clip Length 2160 UHD |
90 frames |
| Still Image Formats |
PNG, TGA, BMP, GIF, JPEG, TIFF |
| Streaming & Recording |
| Direct Streaming |
RTMP melalui Ethernet atau koneksi internet melalui USB-C |
| Recording |
Direct recording ke internal M.2 flash memory opsional atau external media melalui USB-C |
| HD Recording Format |
H.264 .mp4 dengan AAC audio |
| Ultra HD Recording Format |
H.265 HEVC dengan AAC audio |
| Media Format |
ExFAT; APFS atau HFS+ untuk Mac |
| Connectivity |
| Ethernet |
4 × RJ45 dengan built-in network switch, mendukung 10/100/1000/10G BASE-T |
| Computer Interface |
2 × USB-C USB 2.0 untuk recording external drive, webcam output, software control, software update dan switcher connection |
| Webcam Output |
2 × USB-C, mendukung 720p atau 1080p pada PGM frame rate |
| Timecode |
1 × BNC In, 1 × BNC Out |
| Reference |
1 × BNC In, 1 × BNC Out; Tri-Sync atau Black Burst |
| Remote |
RJ12, mendukung RS-422 |
| Talkback |
RJ45 untuk third-party talkback system |
| Internal Timecode Generator |
Yes |
| Control Panel |
| Control Panel |
Integrated broadcast control panel |
| Direct Cross Points |
10 |
| Shifted Cross Points |
20 |
| Crosspoint Button |
Tri-color LED |
| Dedicated Macro Buttons |
10 + Shift 10 |
| Transition Buttons |
5 |
| Key Buttons |
8 |
| AUX Buttons |
12 |
| Fader Bar |
1 |
| Record Buttons |
2 |
| Stream Buttons |
2 |
| 3 Axis Joystick |
1 |
| Software & Operating System |
| Software Control |
ATEM Software Control |
| Software Update |
Melalui USB atau Ethernet menggunakan komputer Mac atau Windows |
| Mac OS |
macOS 14.0 Sonoma, macOS 15.0 Sequoia atau lebih baru |
| Windows |
Windows 10 dan Windows 11 |
| Power & Fisik |
| Power Supply |
Internal 100–240V AC 50/60Hz dengan IEC C14 + 4-pin XLR 12V DC untuk external power atau battery |
| Power Usage |
120W |
| Installation |
Desktop atau in-desk mount |
| Operating Temperature |
0°C hingga 40°C |
| Storage Temperature |
-20°C hingga 60°C |
| Relative Humidity |
0% hingga 90% non-condensing |
