| Camera Features |
|---|
| Product Name |
Blackmagic PYXIS 6K PL |
| Camera Type |
Professional Digital Cinema Camera |
| Effective Sensor Size |
36 × 24 mm (Full Frame) |
| Pixel Pitch |
5.94 microns |
| Optical Low Pass Filter |
Built-in |
| Lens Mount |
Fixed PL Mount with /i Technology |
| Lens Control |
Manual focus dan manual iris |
| Lens Metadata |
Automatic lens data from compatible /i Technology PL lenses |
| Dynamic Range |
13 stops |
| Dual Native ISO |
400 dan 3200 |
| Color Corrector |
DaVinci YRGB |
| 3D LUT |
Custom 3D LUT dapat disimpan dalam metadata file Blackmagic RAW |
| Motion Sensor Data |
Didukung dalam metadata rekaman |
| Slate Metadata |
Project, scene, take, dan special notes |
| Recording Resolutions & Frame Rates |
|---|
| 6K Open Gate 3:2 |
6048 × 4032, hingga 36 fps |
| 6K Anamorphic 6:5 |
4832 × 4032, hingga 36 fps |
| 6K 16:9 |
6048 × 3408, hingga 46 fps |
| 6K DCI 17:9 |
6048 × 3200, hingga 48 fps |
| 6K 2.4:1 |
6048 × 2520, hingga 60 fps |
| Super 35 4:3 |
4096 × 3072, hingga 50 fps |
| 4K 16:9 |
4096 × 2304, hingga 60 fps |
| 4K DCI 17:9 |
4096 × 2160, hingga 60 fps |
| Super 16 16:9 |
2112 × 1184, hingga 100 fps |
| Full HD 16:9 |
1920 × 1080, hingga 120 fps |
| Project Frame Rates |
23.98, 24, 25, 29.97, 30, 50, 59.94 dan 60 fps |
| Off-Speed Recording |
Hingga 60 fps pada 6K 2.4:1 dan 4K DCI 17:9, 100 fps pada Super 16 16:9, serta 120 fps pada Full HD |
| Display & Controls |
|---|
| Screen Size |
4 inci |
| Screen Resolution |
1920 × 1080 |
| Screen Type |
Capacitive LCD touchscreen |
| Screen Brightness |
1500 nits |
| Camera Controls |
Touchscreen menus, physical push buttons dan 3 assignable shortcut keys |
| Focus |
Manual focus only |
| Iris Control |
Manual iris control only |
| Timecode Clock |
Kurang dari 1 frame drift setiap 8 jam |
| Video Connections |
|---|
| Total Video Inputs |
Tidak tersedia |
| 12G-SDI Video Output |
1 × 12G-SDI, hingga 2160p60 |
| Viewfinder Connection |
1 × USB-C dengan power, data, video, dan locking connector |
| SDI Output Standards |
HD dan Ultra HD hingga 2160p60 |
| HD Video Standards |
1080p23.98, 24, 25, 29.97, 30, 50, 59.94 dan 60 |
| Ultra HD Video Standards |
2160p23.98, 24, 25, 29.97, 30, 50, 59.94 dan 60 |
| SDI Compliance |
SMPTE 424M, SMPTE 425M Level A/B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 dan SMPTE 2082-10 |
| SDI Audio Sampling |
48 kHz, 24-bit |
| Audio Connections |
|---|
| Analog Audio Input 1 |
1 × mini XLR, dapat dipilih antara microphone input dengan phantom power atau line level hingga +14 dBu |
| Analog Audio Input 2 |
1 × 3.5 mm stereo input |
| Analog Audio Output |
1 × 3.5 mm headphone jack |
| Built-in Microphone |
Integrated stereo microphone |
| Built-in Speaker |
1 × mono speaker |
| Reference Inputs |
Tri-Sync, Black Burst dan Timecode |
| Media & Recording |
|---|
| CFexpress Slots |
2 × CFexpress Type B |
| External Media |
1 × USB-C 5 Gb/s expansion port |
| Recording Formats |
Blackmagic RAW dan H.264 Proxy |
| Blackmagic RAW Constant Bitrate |
3:1, 5:1, 8:1 dan 12:1 |
| Blackmagic RAW Constant Quality |
Q0, Q1, Q3 dan Q5 |
| H.264 Proxy |
1920 × 1080, 8-bit 4:2:0 |
| Blackmagic RAW Resolutions |
6048 × 4032, 4832 × 4032, 6048 × 3408, 6048 × 3200, 6048 × 2520, 4096 × 3072, 4096 × 2304, 4096 × 2160, 2112 × 1184 dan 1920 × 1080 |
| Recording Dynamic Range |
Film, Extended Video, Video Dynamic Range dan custom 3D LUT sesuai format yang didukung |
| Pre-Record Mode |
Durasi 5, 10, 20, 30 detik, 1, 2, 5 dan 10 menit |
| Media File Systems |
ExFAT untuk Windows/Mac atau HFS+ untuk Mac |
| Portrait Metadata |
Supported untuk semua resolusi Blackmagic RAW dan H.264 Proxy |
| USB, Network & Remote Control |
|---|
| Computer Interface |
USB Type-C untuk external drive recording, PTP camera control dan software updates |
| Ethernet |
1 × RJ45 1Gb/s, mendukung 10/100/1000 BASE-T |
| Camera Control |
iPad control, Bluetooth control, USB PTP camera control, dan Camera Control REST API melalui Ethernet |
| Focus & Zoom Control |
Kompatibel dengan Blackmagic Focus Demand dan Blackmagic Zoom Demand |
| Network Time Protocol |
Supported untuk sinkronisasi waktu melalui jaringan dengan NTP server |
| Web Media Manager |
Akses browser untuk browse, download dan delete files pada media yang terhubung |
| FTP |
Download files dari media yang terhubung melalui FTP |
| SMB |
File sharing melalui SMB |
| Blackmagic Cloud |
Supported untuk workflow sinkronisasi media dan kolaborasi yang kompatibel |
| Software & Operating System |
|---|
| Operating System |
Blackmagic OS |
| Included Software |
DaVinci Resolve Studio untuk Mac dan Windows, termasuk activation key |
| Additional Software |
Blackmagic Camera Setup, Blackmagic RAW Player, Blackmagic RAW QuickLook Plugin, Blackmagic RAW SDK dan Blackmagic RAW Speed Test |
| macOS |
macOS 13 Ventura, macOS 14 Sonoma atau lebih baru |
| Windows |
Windows 10 dan Windows 11 |
| Power Requirements |
|---|
| Power Supply |
1 × external 12V DC 60W power supply |
| External Power Connector |
1 × 2-pin LEMO-compatible locking connector |
| Compatible Battery Type |
BP-U series |
| Power Input Range |
11–19.5V |
| Environmental Specifications |
|---|
| Operating Temperature |
0°C hingga 40°C |
| Storage Temperature |
-20°C hingga 45°C |
| Relative Humidity |
0% hingga 90%, non-condensing |
| Optional Accessories |
|---|
| Camera Handle |
Blackmagic URSA Cine Handle |
| Electronic Viewfinder |
Blackmagic URSA Cine EVF |
| Side Plate |
Blackmagic PYXIS Rosette Plate |
| External Monitor |
Blackmagic PYXIS Monitor, PYXIS Monitor Kit dan PYXIS Monitor EVF Kit |
| Lens |
PL-mount cinema lenses, dijual terpisah |
