| Camera Features |
|---|
| Product Name |
Blackmagic Studio Camera 4K Plus G2 |
| Camera Type |
Professional Studio Camera |
| Effective Sensor Size |
17,78 × 10 mm (Four Thirds) |
| Lens Mount |
Active MFT Mount |
| Lens Control |
Iris, focus dan zoom pada lensa yang kompatibel |
| Dynamic Range |
13 stops |
| Dual Native ISO |
0 dB dan 18 dB gain |
| Sensitivity at 0 dB Gain |
f/11 pada 2160p59.94 dan f/12 pada 2160p50, di 2.000 lux dengan reflectance 89,9% |
| Signal-to-Noise Ratio |
63 dB pada 2160p |
| Color Corrector |
DaVinci YRGB |
| Recording Resolution & Frame Rates |
|---|
| Maximum Resolution |
3840 × 2160 Ultra HD |
| Maximum Frame Rate |
Hingga 60 fps dalam Ultra HD |
| Project Frame Rates |
23.98, 24, 25, 29.97, 30, 50, 59.94 dan 60 fps |
| Off-Speed Recording |
Hingga 60 fps dalam Ultra HD |
| Autofocus |
Didukung dengan lensa yang kompatibel |
| Display & Controls |
|---|
| Screen Size |
7 inci |
| Screen Resolution |
1920 × 1200 |
| Screen Type |
LCD capacitive touchscreen |
| Screen Brightness |
600 nits |
| Camera Controls |
Touchscreen camera settings dan menu, rotary settings dial, program button, F1/F2/F3 assignable function buttons, brightness, contrast dan peaking dials |
| Mounting Options |
2 × 1/4-inch tripod mount dan 1 × 3/8-inch tripod mount |
| Video Connections |
|---|
| SDI Video Input |
1 × SDI input, digunakan untuk program return dan reference sesuai sistem yang kompatibel |
| SDI Video Output |
1 × SDI output |
| SDI Rates |
1.5G, 3G, 6G dan 12G-SDI |
| HDMI Output |
1 × HDMI 2.0 |
| HDMI Output Standards |
HD dan Ultra HD hingga 2160p60 |
| Remote Camera Control |
Melalui SDI, HDMI atau USB Ethernet dengan sistem yang kompatibel |
| Reference Input |
Program SDI input pada kamera |
| SDI Embedded Audio |
2 channel program audio pada 1.5G/3G/6G/12G-SDI dan 2 talkback channels pada kanal 15 dan 16 |
| SDI Compliance |
SMPTE 292M, SMPTE 424M, SMPTE 425M Level A/B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 dan SMPTE 2082-10 |
| Audio |
|---|
| Built-in Microphone |
Integrated stereo microphone |
| Built-in Speaker |
1 × mono speaker |
| Analog Audio Input |
1 × 3,5 mm stereo input, dapat digunakan sebagai timecode input |
| Analog Audio Output |
1 × 3,5 mm TRRS mini jack untuk headphone dengan mikrofon |
| SDI Audio Sampling |
48 kHz, 24-bit |
| HDMI Audio Sampling |
48 kHz, 24-bit |
| Talkback |
Melalui SDI channels 15 dan 16 |
| Recording & Storage |
|---|
| Recording Media |
2 × USB-C 3.1 Gen 1 expansion ports untuk media eksternal |
| Recording Codec |
Blackmagic RAW |
| Recording Resolution |
3840 × 2160 Ultra HD pada frame rate yang dipilih |
| Constant Bitrate |
Blackmagic RAW 3:1, 5:1, 8:1 dan 12:1 |
| Constant Quality |
Blackmagic RAW Q0, Q1, Q3 dan Q5 |
| Media File Systems |
ExFAT untuk Windows/Mac atau HFS+ untuk Mac |
| Recording Storage Rate at 30 fps |
3:1 = 127 MB/s; 5:1 = 77 MB/s; 8:1 = 48 MB/s; 12:1 = 32 MB/s |
| USB-C Port Functions |
External media recording dan koneksi Focus Demand/Zoom Demand yang kompatibel |
| Camera Control & Network Management |
|---|
| External Control |
Blackmagic Zoom Demand dan Blackmagic Focus Demand |
| ATEM Integration |
Blackmagic Control Protocol melalui SDI dan HDMI saat digunakan dengan ATEM switcher yang kompatibel |
| Remote Control Functions |
Pengaturan kamera yang kompatibel, focus, iris, zoom, color corrector, tally dan record start/stop ke media USB-C eksternal |
| Camera Control REST API |
Melalui USB Ethernet dengan aplikasi REST client yang kompatibel |
| Network Time Protocol |
Supported melalui jaringan dengan NTP server |
| Web Media Manager |
Akses browser untuk browse, download dan delete file dari media yang terhubung |
| FTP |
Download file melalui FTP |
| SMB |
File sharing melalui SMB |
| Physical Ethernet Port |
Tidak tersedia port Ethernet RJ45 bawaan; fitur jaringan memerlukan konfigurasi USB Ethernet yang kompatibel |
| Direct RTMP Streaming |
Tidak tersedia sebagai fitur bawaan model Plus G2 |
| Tally & Camera Monitoring |
|---|
| Live Tally Indicators |
1 × front-facing untuk talent dan 1 × rear-facing untuk operator |
| Talkback Channels |
SDI channels 15 dan 16 |
| Color Correction |
DaVinci YRGB built-in color corrector |
| Software & Compatibility |
|---|
| Operating System |
Blackmagic OS |
| Software Included |
Blackmagic Camera Setup untuk Mac dan Windows |
| macOS |
macOS 13 Ventura, macOS 14 Sonoma atau lebih baru |
| Windows |
Windows 10 dan Windows 11 |
| Firmware Update |
Melalui USB-C Port A |
| Power Requirements |
|---|
| Power Supply |
1 × external 12V DC 60W power supply |
| Power Input |
1 × 12V DC locking 5,5 mm barrel connector |
| Power Consumption |
15–22W |
| Environmental Specifications |
|---|
| Operating Temperature |
0°C hingga 40°C |
| Storage Temperature |
-20°C hingga 45°C |
| Relative Humidity |
0% hingga 90%, non-condensing |
| Optional Accessories |
|---|
| Focus Control |
Blackmagic Focus Demand |
| Zoom Control |
Blackmagic Zoom Demand |
| Compatible Switchers |
ATEM Mini switchers serta ATEM Television Studio HD dan HD Pro switchers yang kompatibel |
| Additional Accessories |
Blackmagic Studio Camera Sun Shade dan aksesori rigging yang kompatibel |
